Analysis and Improvement of Transmission Characteristic for Tunable Optical Drop Filter

Main Article Content

Jeerapa Phelawan
Sommart Sangngern


This paper proposes improvement of transmission characteristic for tunable optical drop filter. The results of the transmission characteristic analysis to output port ( ) found that the side mode appears is rather which this causes more crash of the signal detection to the receiver bring the optical amplifier mix with optical ring resonator of tunable optical drop filter due to the optical amplifier affect to the finesse transfiguration of optical ring resonator and adjust the optical gain of the optical amplifier found that a side mode decreased. The optical gain is 5 and will be decreased of side mode is 0. The result of improvement the transmission characteristic of the optical filter can be applied to DWDM passive optical network and reduce error in the receiver.

Article Details

Research Articles


L. Jean-Pierre, “DWDM Fundamentals Components and Applications, Artech House”, 2002.

S. Weinstein, Y.Luo, T.Wang, “Passive Optical Network”, IEEE PRESS, 2012.

International Telecommunication Union, Telecommunication Standardization Sector, ITU-T G. 694.1, February 2012.

S. Jirakitkul and A. Roeksabutr, “25 GHz DWDM Demultiplexer Using Ring Resonator with MZI in the Loop”, IEEE-ISCIT 2003, pp 889-892, 2003.

C. Vazquez, J. Montalvo, P. C. Lallana, “Ring Resonators with Sagnac Loops for Phonic Processing in DWDM Backbone Networks”, WISP 2007, October 2007.

Y. Ding, M. Pu, L. Liu, J. Xu, C. Peucheret, X. Zhang, D. Huang, and H. Ou, “Bandwidth and wavelength-tunable optical bandpass filter based on silicon microring-MZI structure”, OPTICS EXPRESS, vol. 19, No. 7, March 2011.

จีรภา เพลาวัน และ สมมาตร แสงเงิน, “ตัวกรองสัญญาณแสงแบบดรอปปรับค่าได้สำหรับการสื่อสารบนโครงข่ายเชิงแสงแบบพาสซีพด้วยเทคนิคการมัลติเพลกซ์เชิงแบบ DWDM”, งานประชุมวิชาการงานวัจัยและพัฒนาเชิงประยุกต์ครั้งที่ 10 (ECTI-CARD 2018), มิถุนายน 2561.

H. Okamura and K. Iwatsuki, “A Finesse-Enhanced Er-Doped-Fiber Ring Resonator”, Journal of Lightwave Technology, vol. 9, No. 11, November 1991.

Li. Jun Qing, A. Bananej, Li. Qiang Hua, C. Qiang, Li. Chun Fei, “An all-optical switch of Mach-Zehnder interferometer type using an active fiber ring resonator”, J of Chin. Phys., vol. 13, No. 7, pp. 1046-1051, July 2004.
